How to turn on and off the power of the remote cameras
How to turn on the power of the remote
cameras
The power of the remote cameras in the standby state can be turned on
from the unit
There are the following methods of turning on the power
Turning on the power one camera at a time
Turning on the power of the cameras simultaneously with the turning
on of the unit’s power
Turning on the power of multiple cameras
Turning on the power of all the cameras
Turning on the power of the selected camera group
Each of these methods is described in turn below
Turning on the power one camera at a time
1 Select the remote camera
When the corresponding camera selection button
[CAMERA SELECT/GROUP SELECT] is held down for
approximately 3 seconds, the name of the remote camera is
displayed on the top line of the LCD panel and “POWER: OFF↓” is
displayed on the bottom line
2 Turn the F2 dial to select “ON” while keeping the camera
selection button held down and then press the F2 dial
1
2
CAM1 < A W-HE120>
POWER:ON
Turning on the power of the cameras simultaneously
with the turning on of the unit’s power
1 Set the MENU button to ON
2 Open CAMERA SETUP menu [24]
3 Turn the F1 dial to display the “2 AUTO ON” item
2.AUTO ON
On
4 Turn the F2 dial to select “On” and press the F2 dial
The power of the remote cameras set to “Serial” or “Network” in
CTRL TYPE menu [36] will now turn on simultaneously with the
turning on of the unit’s power
Depending on the number of cameras connected, it may take
some time before you can operate the unit
Note
Turning on the power of multiple cameras
1 Set the MENU button to ON
Press the MENU button to turn on its indicator
2 Open CAMERA SETUP menu [24]
3 Turn the F1 dial to display the “1 CAM POWER” item
1.CAM POWER
GROUP ON
Turning on the power of all the cameras
4 Turn the F2 dial to select “ALL ON” and press the F2
dial
1.CAM POWER
ALL ON
Turning on the power of the selected camera group
4 Turn the F2 dial to select “GROUP ON” and press the F2
dial
1.CAM POWER
GROUP ON
