Panasonic AWRP120

53
Table of setting items (menus)
Button
number
Menu name Setting item Remote camera
Initial value on
unit
(
*
1)
Setting
(
*
2)
[21] SHUTTER 1 SHUTTER AW‑HE120 – Off, Step, Synchro, ELC
AW‑HE50, AW‑HE60 – Off, Step, Synchro
AW‑HE2 – “‑‑‑”
AW‑HE100 – Off, Step, Synchro
AW‑HE870 – Off, Step, Synchro, ELC
AW‑E860, AW‑E750,
AW‑E650, AW‑E350
– Off, Step, Synchro, ELC
AK‑HC1500, AK‑HC1800 – Off, Step, Synchro
2 SPEED AW‑HE120 – 5994 Hz:
1/100, 1/250, 1/500, 1/1000, 1/2000,
1/4000, 1/10000
50 Hz:
1/120, 1/250, 1/500, 1/1000, 1/2000,
1/4000, 1/10000
AW‑HE50, AW‑HE60 – 1/100, 1/250, 1/500, 1/1000, 1/2000,
1/4000, 1/10000
AW‑HE2 – “‑‑‑”
AW‑HE100 – 1/100, 1/250, 1/500, 1/1000, 1/2000
AW‑HE870 – 1/100, 1/250, 1/500, 1/1000, 1/2000,
1/4000, 1/10000
AW‑E860, AW‑E750,
AW‑E650, AW‑E350
– 1/100, 1/250, 1/500, 1/1000, 1/2000,
1/4000, 1/10000
AK‑HC1500, AK‑HC1800 – VIDEO:
1/100, 1/120, 1/250, 1/500, 1/1000,
1/2000
FILM:
1800, 1728, 1440, 1200, 900, 450
[22] ND FILTER 1 ND FILTER – ND1, ND2, ND3, ND4
[23] FUNCTION 1 OPTION – Off, On
2 DEFROSTER – Off, On
3 WIPER – Off, On
4 HEATER/FAN – Off, On
5 LAMP
– Off, On
[24] CAMERA SETUP 1 CAM POWER GROUP ON GROUP OFF, GROUP ON, ALL OFF,
ALL ON
2 AUTO ON On On, Off
3 RECALL PST SPD Off On, Off
4 TALLY OUT Off On, Off
5 HOME POSITION SET SET
[25] RP SETUP 1 FOCUS/IRIS STANDARD STANDARD, EXCHANGE
2 P/T CURV 1 1 to 5
3 LCD BACKLIGHT On On, Off, 60, 120, 180
4 ENABLE BUTTON ACTIVE ACTIVE, LOCK
5 MENU CONTROL ACTIVE ACTIVE, LOCK
6 GLOBAL AREA Off On, Off
7 IP ADDRESS 19216809
8 SUBNETMASK 2552552550
9 GATEWAY 19216801
10 MAC ADDRESS Displayed only
11 PORT CAM1 61000 61000 to 65535
… … …
20 PORT CAM10 61009 61000 to 65535
[26] PAN DIRECTION 1 CAM1 NORMAL NORMAL, REVERSE
… … …
100 CAM100 NORMAL NORMAL, REVERSE
[27] TILT DIRECTION 1 CAM1 NORMAL NORMAL, REVERSE
… … …
100 CAM100 NORMAL NORMAL, REVERSE
[28] ZOOM DIRECTION 1 CAM1 NORMAL NORMAL, REVERSE
… … …
100 CAM100 NORMAL NORMAL, REVERSE
[29] FOCUS DIRECTION 1 CAM1 NORMAL NORMAL, REVERSE
… … …
100 CAM100 NORMAL NORMAL, REVERSE
(
*
1) “–” indicates a setting saved to the remote camera
A diagonal line indicates a setting that can only be displayed It cannot be changed
(
*
2) “‑‑‑” indicates a setting that cannot be changed
