Input
signal
Communication
port
Name Description
Effective
operation
mode
XE
Clear to send
flag
communication mode. It turns off (0) in other
modes.
For COM.3 Port
XF For COM.4 Port
X10 For COM.1 Port
Reset done
When the communication channel is reset under
the output Y10 to Y13, the flag is turned on (1)
once the resetting operation is completed.
Resetting done: 1
Y10 to Y12 is off: 0
General-
purpose
communicatio
n
X11 For COM.2 Port
X12 For COM.3 Port
X13 For COM.4 Port
X14 For COM.1 Port
CTS signal
monitor
Status of the CTS signal sent from the device
communicating with.
Clear to send from COM.1/COM.3 port = 0
Cannot send from COM.1/COM.3 port = 1
The RTS signal can be controlled with Y14/Y16
When RS/CS
is set to valid
in
communicatio
n Cassette
COM.1/COM.3
X16 For COM.3 Port
X15
- Not used Do not use this.
X17 to
X1F
(Note 1) The general-purpose communication reception done (copy) flag is effective after the execution of the
RECV instruction until one of the following instructions is executed. This flag does not remain ON
across several scans.
Execute 1: END instruction (scan header), and 2: RECV instruction
(Note 2) The I/O numbers actually allocated are the numbers based on the starting word number allocated to
the unit.
Example) When the starting word number for the unit is "10", the general-purpose communication
reception done flag for COM.1 port is X100.
■
Output signal
Outpu
t
signal
Communication
port
Name Description
Effective
operation
mode
Y0 For COM.1 Port
Sending
done result
Reports the results of sending in master
communication or general-purpose communication.
Normal completion: 0, Abnormal completion: 1
MEWTOCOL
MODBUS RTU
General-
purpose
communication
Y1 For COM.2 Port
Y2 For COM.3 Port
Y3 For COM.4 Port
Y4 to
Y7
- Undefined Do not turn on "undefined". (Default setting is 0.)
Y8 For COM.1 Port General-
purpose
communica
tion
Sending
active
flag
It turns on (1) during sending in the general-purpose
communication mode.
(Note 1)
Sending done: 0, Sending: 1
General-
purpose
communication
Y9 For COM.2 Port
YA For COM.3 Port
YB For COM.4 Port
YC For COM.1 Port
Master
communica
tion
Send active
It turns on (1) during sending in the master
communication mode.
Sending done: 0, Sending: 1
MEWTOCOL
MODBUS RTU
YD For COM.2 Port
YE For COM.3 Port
4.1 Input/Output Signals Used for Communication
WUME-FP7COM-07 4-5
