15.3. USS RELAY Board
15.3.1. USS RELAY Board (for KV-S5076H)
Safety Ref. No. Part No. Part Name & Description Remarks
CN2006 K1MY28BA0516 CONNECTOR
CN2007 K1KA24BA0124 CONNECTOR
CN2008 K1KA04BA0061 CONNECTOR
CN2009 K1KA03BA0061 CONNECTOR
CN2018 K1KA04BA0061 CONNECTOR
R2050 ERX12SJ7R5V 7.5
R2053 ERX12SJ7R5V 7.5
C2001 ECJ1VF1H104Z 0.1
C2002 ECUV1H102KBV 0.001
C2003 ECUV1H102KBV 0.001
C2004 ECUV1H102KBV 0.001
C2005 ECUV1E104ZFV 0.1 S
C2006 ECUV1H102KBV 0.001
C2007 ECUV1H561JCV 560p
C2008 ECUV1E104ZFV 0.1 S
C2009 ECUV1E104ZFV 0.1 S
C2010 ECUV1H102KBV 0.001
C2011 ECUV1E104ZFV 0.1 S
C2012 ECUV1E104ZFV 0.1 S
C2013 ECUV1H103KBV 0.01 S
C2014 ECUV1H103KBV 0.01 S
C2015 ECUV1E104ZFV 0.1 S
C2016 ECUV1H102KBV 0.001
C2018 ECJ1VF1H104Z 0.1
C2019 ECJ1VF1H104Z 0.1
C2021 ECUV1E104ZFV 0.1 S
C2022 EEE1VA101XP 100
C2023 ECUV1E104ZFV 0.1 S
C2024 ECJ1VF1H104Z 0.1
C2025 ECUV1H102KBV 0.001
C2026 ECUV1H102KBV 0.001
C2027 ECUV1H102KBV 0.001
C2029 ECUV1H102KBV 0.001
C2030 ECUV1H102KBV 0.001
C2031 ECUV1H102KBV 0.001
C2034 ECUV1E104ZFV 0.1 S
C2035 EEE1AA101SP 100
C2036 ECUV1E104ZFV 0.1 S
C2037 F2G1E2210017 220
C2038 ECUV1H102KBV 0.001
C2039 ECUV1H102KBV 0.001
C2040 ECUV1H102KBV 0.001
C2041 ECJ1VF1H104Z 0.1
C2042 ECUV1H101JCV 100p
C2043 ECUV1H101JCV 100p
C2045 ECUV1H102KBV 0.001
C2047 ECUV1E104ZFV 0.1 S
C2048 ECUV1E104ZFV 0.1 S
C2050 ECUV1H101JCV 100p
C2051 ECUV1H101JCV 100p
C2052 ECUV1H102KBV 0.001
C2053 ECUV1H102KBV 0.001
C2055 ECUV1H102KBV 0.001
C2056 ECJ1VF1H104Z 0.1
C2057 ECUV1H561JCV 560p
C2058 ECUV1E104ZFV 0.1 S
C2059 ECUV1H561JCV 560p
C2060 ECUV1H103KBV 0.01 S
C2061 EEE1AA101SP 100
C2062 ECUV1H102KBV 0.001
C2063 ECUV1E104ZFV 0.1 S
C2064 ECUV1H102KBV 0.001
C2065 ECJ1VF1H104Z 0.1
C2066 F1H1E105A100 CERAMIC CAPACITOR
C2067 F1H1E105A100 CERAMIC CAPACITOR
D2003 1SS355 DIODE(SI) S
D2004 1SS355 DIODE(SI) S
IC2001 C0ABBA000093 IC
