325
15.20. SKEW SENSOR(R) Board (KV-S5076H ONLY)
15.21. PLATEN SENSOR(F) Board
15.22. PLATEN SENSOR(B) Board
15.23. USR SENSOR Board
15.24. SLIP DETECT SENSOR Board
15.25. STARTING SENSOR Board
Safety Ref. No. Part No. Part Name & Description Remarks
CN3019 K1KA04BA0061 CONNECTOR
CN3027 K4CF01000033 CONNECTOR
IC3007 B3NAB0000050 PHOTO ELECTRIC TRANSDUCER
C3009 F1H1E104A029 CERAMIC CAPACITOR
Q3007 B1ADCF000001 TRANSISTOR(SI)
R3009 ERJ3GEYJ473 47k
R3010 PQ4R18XJ151 150 S
Safety Ref. No. Part No. Part Name & Description Remarks
CN3021 K1KA03BA0061 CONNECTOR
IC3008 B3NAA0000106 PHOTO ELECTRIC TRANSDUCER
C3011 F1H1E104A029 CERAMIC CAPACITOR
R3011 ERJ3GEYJ331 330
Safety Ref. No. Part No. Part Name & Description Remarks
CN3022 K1KA03BA0061 CONNECTOR
CN3028 K4CF01000033 CONNECTOR !
IC3009 B3NAA0000106 PHOTO ELECTRIC TRANSDUCER
C3012 F1H1E104A029 CERAMIC CAPACITOR
R3012 ERJ3GEYJ331 330
Safety Ref. No. Part No. Part Name & Description Remarks
CN3005 K1KA03BA0061 CONNECTOR
SN3001 L2FA00000017 PHOTO ELECTRIC TRANSDUCER
Safety Ref. No. Part No. Part Name & Description Remarks
CN3006 K1KA04BA0061 CONNECTOR
IC3012 B3NAB0000050 PHOTO ELECTRIC TRANSDUCER
C3016 ECJ1VF1E104Z 0.1
C3017 ECUV1H102KBV 0.001
Q3008 B1ADCF000001 TRANSISTOR(SI)
R3013 ERJ3GEYJ473 47k
R3014 PQ4R18XJ151 150 S
R3070 ERJ3GEY0R00 0
Safety Ref. No. Part No. Part Name & Description Remarks
CN3018 K1KA03BA0061 CONNECTOR
D3003 B3EA00000168 DIODE(SI)
D3004 B3EA00000168 DIODE(SI)
LS3009 LH-5S-3 SPACER
LS3010 LH-5S-3 SPACER
