Panasonic KV-S5046H - CIS(B) RELAY Board Replacement Parts; BENT RELAY Board Replacement Parts

321
15.7. CIS(B) RELAY Board
15.8. BENT RELAY Board
15.9. BACK LIGHT LED Board (KV-S5076H ONLY)
15.10. DFP HOME SENSOR Board
15.11. ENDING SENSOR Board
R2166 ERJ3GEY0R00 0
R2167 ERJ3GEY0R00 0
Safety Ref. No. Part No. Part Name & Description Remarks
Safety Ref. No. Part No. Part Name & Description Remarks
CN2026 K1KA16BA0053 CONNECTOR
CN2027 K1KA09BA0061 CONNECTOR
C2110 F1J1A106A024 CERAMIC CAPACITOR
C2111 F1J1A106A024 CERAMIC CAPACITOR
C2112 ECUV0J225KBV 2.2 S
C2113 ECUV0J225KBV 2.2 S
C2114 F1H1C104A041 CERAMIC CAPACITOR
C2115 F1H1C104A041 CERAMIC CAPACITOR
CN2025 K1MY50BA0635 CONNECTOR
D2008 DB2J20100L DIODE(SI)
IC2016 C0DBGYY00635 CONNECTOR
L2046 PQLQR2KB113T COIL S
L2047 PQLQR2KB113T COIL S
L2048 PQLQR2KB113T COIL S
L2049 PQLQR2KB113T COIL S
L2050 PQLQR2KB113T COIL S
L2074 PQLQR2KB113T COIL S
L2075 PQLQR2KB113T COIL S
L2076 PQLQR2KB113T COIL S
L2077 PQLQR2KB113T COIL S
L2078 PQLQR2KB113T COIL S
R2168 ERJ3GEY0R00 0
R2169 ERJ3GEY0R00 0
Safety Ref. No. Part No. Part Name & Description Remarks
CN2030 K1KA24AA0178 CONNECTOR
CN2031 K1KA05AA0193 CONNECTOR
CN2032 K1KA06A00452 CONNECTOR
CN2033 K1KA04AA0193 CONNECTOR
CN2034 K1KA08A00520 CONNECTOR
CN2035 K1KA04AA0186 CONNECTOR
CN2036 K1KA04AA0258 CONNECTOR
CN2037 K1KA05AA0258 CONNECTOR
Safety Ref. No. Part No. Part Name & Description Remarks
CN2019 K1KA02B00236 CONNECTOR
D2011 B3AFB0000370 DIODE(SI)
Safety Ref. No. Part No. Part Name & Description Remarks
CN3002 K1KA04BA0061 CONNECTOR
IC3001 B3NAA0000106 PHOTO ELECTRIC TRANSDUCER
IC3004 B3NAA0000106 PHOTO ELECTRIC TRANSDUCER
C3001 F1H1E104A029 CERAMIC CAPACITOR
R3001 ERJ3GEYJ331 330
R3005 ERJ3GEYJ331 330
Safety Ref. No. Part No. Part Name & Description Remarks
CN3003 K1KA04BA0061 CONNECTOR
IC3002 B3NAB0000050 PHOTO ELECTRIC TRANSDUCER
C3002 F1H1E104A029 CERAMIC CAPACITOR
Q3001 B1ADCF000001 TRANSISTOR(SI)
R3002 ERJ3GEYJ473 47k
R3003 PQ4R18XJ151 150 S
