324
15.18. HOPPER POSITION SENSOR Board
15.19. SKEW SENSOR(L) Board (KV-S5076H ONLY)
C3022 ECJ1VF1E104Z 0.1
C3023 ECJ1VF1E104Z 0.1
C3026 ECUV1H561KBV 560p
C3027 ECUV1H561KBV 560p
C3028 ECUV1H561KBV 560p
C3029 ECJ1VC1H151J 150p
C3030 ECUV1H102KBV 0.001
C3031 ECJ1VC1H391J 390p
C3032 ECUV1H101JCV 100p
C3033 ECUV1H101JCV 100p
C3034 ECUV1H101JCV 100p
IC3010 C1ZBZ0004019 IC
Q3012 B1GBCFEN0010 TRANSISTOR(SI) S
Q3013 B1GBCFEN0010 TRANSISTOR(SI) S
R3017 ERJ3GEYJ222 2.2k
R3018 ERJ3GEYJ102 1k
R3019 ERJ3GEYJ181 180
R3020 ERJ3GEYJ181 180
R3026 ERJ3GSYJ103 10k S
R3029 ERJ3GSYJ103 10k S
R3030 ERJ3GSYJ103 10k S
R3032 ERJ3GEYJ101 100
R3033 ERJ3GEYJ102 1k
R3034 PQ4R18XJ122 1.2k S
R3035 PQ4R18XJ122 1.2k S
R3036 ERJ3GEYJ101 100
R3037 ERJ3GEYJ101 100
R3038 ERJ3GEYJ101 100
R3039 ERJ3GEYJ101 100
R3040 ERJ3GEYJ332 3.3k
R3041 ERJ3GSYJ103 10k S
R3042 ERJ3GSYJ103 10k S
R3045 ERJ3GEYJ181 180
R3046 ERJ3GEY0R00 0
R3047 ERJ3GEY0R00 0
R3050 ERJ3GEY0R00 0
R3051 ERJ3GEY0R00 0
R3052 ERJ3GEY0R00 0
R3053 ERJ3GEY0R00 0
R3054 ERJ3GEY0R00 0
R3055 ERJ3GEY0R00 0
R3056 ERJ3GEY0R00 0
R3058 ERJ14Y0R00 0
R3073 ERJ3GEY0R00 0
R3074 ERJ3GEY0R00 0
R3075 ERJ14Y0R00 0
R3076 ERJ3GEY0R00 0
R3077 ERJ3GEY0R00 0
R3078 ERJ14Y0R00 0
R3079 ERJ14Y0R00 0
R3080 ERJ14Y0R00 0
Safety Ref. No. Part No. Part Name & Description Remarks
Safety Ref. No. Part No. Part Name & Description Remarks
CN3024 K1KA04BA0125 CONNECTOR
IC3005 B3NAA0000106 PHOTO ELECTRIC TRANSDUCER
C3006 F1H1E104A029 CERAMIC CAPACITOR
R3006 ERJ3GEYJ331 330
Safety Ref. No. Part No. Part Name & Description Remarks
CN3020 K1KA04BA0061 CONNECTOR
CN3026 K4CF01000033 CONNECTOR
IC3006 B3NAB0000050 PHOTO ELECTRIC TRANSDUCER
C3007 F1H1E104A029 CERAMIC CAPACITOR
Q3006 B1ADCF000001 TRANSISTOR(SI)
R3007 ERJ3GEYJ473 47k
R3008 PQ4R18XJ151 150 S
R3060 ERJ3GEY0R00 0
R3061 ERJ3GEY0R00 0
