Panasonic KX-NS Series Installation Manual

c. Move the mouse pointer over the V-IPEXT32 card (Virtual IP Extension Card).
A menu will be shown under the mouse pointer.
d. Click Port Property.
e. Click the Remote Place tab.
f. Configure the items shown below.
• Change the value to Remote (MRG) for Phone Location.
g. Click OK.
3. Unplug
the AC adaptor of the IP-PT, and then plug it in again to reboot the IP-PT manually. The IP-PT will
download settings automatically.
Installing IP-CSs (KX-NS0154 only) at a remote site with Built-in Media Relay
Gateway
You can install IP-CSs (KX-NS0154 only) at the remote site directly or from the local site as follows.
1. Register the IP-CS. For details, refer to corresponding manuals of KX-NS0154.
2. Program the settings for the IP-CS.
a. Click Setup ® PBX Configuration ® Configuration ® Slot.
b. Click Virtual ® V-IPCS4.
c. Move the mouse pointer over the V-IPCS4 card (Virtual 4 IP Cell Station Interface Card).
A menu will be shown under the mouse pointer.
d. Click Port Property.
e. Click the Remote Place tab.
f. Configure the items shown below.
• Change the value to Remote (MRG) for Phone Location.
g. Click OK.
3. Unplug the AC adaptor of the IP-CS, and then plug it in again to reboot the IP-CS manually. The IP-CS
will download settings automatically.
Installing KX-UT series SIP phones at a remote site with Built-in Media Relay
Gateway
There are 2 methods to install KX-UT series SIP phones at a remote site:
• Set up the phones at the main site using the PBX, and then send them to the remote site.
• Set up the phones without connecting them to the PBX at the main site, and then send them to the remote
site.
Setting up KX-UT series SIP phones at the main site, and then sending them to remote site
1. Register the phone. For details, refer to "5.8.1 Registering IP Telephones".
2. Program the settings for the phone.
a. Click Setup ® PBX Configuration ® Configuration ® Slot.
b. Click Virtual ® V-UTEXT32.
c. Move the mouse pointer over the V-UTEXT32 card (Virtual UT Extension Card).
A menu will be shown under the mouse pointer.
d. Click Port Property.
e. Click the Remote Place tab.
f. Configure the items shown below.
• Change the value to Remote (MRG) for Phone Location.
• Select a protocol (HTTP/HTTPS) for Protocol for Remote SIP-MLT.
242 Installation Manual Document Version 2016-03
5.8.4 Installing IP Phones at a Remote Site with a Built-in Media Relay Gateway
