CO Line Option Card Installing Restrictions
The following tables show which combinations of optional CO line cards can be installed.
ü: Available
—: Not available
KX-NS700
2nd Slot
LCOT6 PRI23 DPH2
1st Slot
LCOT6
ü ü ü
PRI23
ü
—
*1
ü
DPH2
ü ü
—
*1
*1
This installation combination is not available due to software restrictions.
KX-NS720
2nd Slot
LCOT6 PRI23 DPH2
1st Slot
LCOT6
ü ü ü
PRI23
ü
—
*1
ü
DPH2
ü ü
—
*1
*1
This installation combination is not available due to software restrictions.
Extension Option Card Installing Restrictions
There are no restrictions on the available combinations of optional extension cards, so long as the maximum
number of cards for the extension type is not exceeded.
Document Version 2016-03 Installation Manual 45
2.3.3 System Capacity
