Panasonic KX-NS Series Installation Manual

IP-CS Channel Expansion
Model No. Activation Key Type Description
Maximum Activation
Keys
KX-NSE201 1 IP-CS channel
expansion
Increases the number of
communication channels from 4
to 8 for 1 IP-CS (KX-NS0154
only).
32
KX-NSE205 5 IP-CS channel
expansion
Increases the number of
communication channels from 4
to 8 for 5 IP-CSs (KX-NS0154
only).
KX-NSE210 10 IP-CS channel
expansion
Increases the number of
communication channels from 4
to 8 for 10 IP-CSs (KX-NS0154
only).
KX-NSE220 20 IP-CS channel
expansion
Increases the number of
communication channels from 4
to 8 for 20 IP-CSs (KX-NS0154
only).
Note
• When
performing channel expansion for IP-CSs (KX-NS0154 only) change the status of the IP-CS port
to OUS, then enable the channel expansion setting. (See "9.18 PBX Configuration—[1-1]
Configuration—Slot—Port Property—V-IPCS—Main—
Channel expansion"
in the PC Programming
Manual.)
• To apply the channel expansion, the IP-CSs (KX-NS0154 only) must be reset by changing their port
status from OUS to INS. (See "9.18 PBX Configuration—[1-1] Configuration—Slot—Port
Property—V-IPCS—Main—
Connection" in the PC Programming Manual.)
Feature Manual References for Related Features of Activation Keys
10.1.16 IP-CS (KX-NS0154)
Networking
Model No. Activation Key Type Description
Maximum Activation Keys
Stand-alone
System
One-look
Network
KX-NSN001 One-look Network Allows the use of multi-site
connections using One
-look
network feature.
–
16 activation
keys
*1
KX-NSN002 QSIG Network Allows the use of enhanced
QSIG network features (NDSS,
Centralized Voice Mail, etc.).
1 activation key
*1
This activation key must be installed to each PBX in the One
-look network.
56 Installation Manual Document Version 2016-03
3.1.1 Type and Maximum Number of Activation Keys
