Ph: 804.227.3023
10511 Old Ridge Rd. Ashland, VA 23005
v 2.0
Powertrain Control Solutions
PCS D200 Dash Logger User Guide
1 Introduction
The D200 Dash Logger is a powerful combination of high speed data logging and a graphical touchscreen LCD
providing a complete vehicle monitoring and data logging system.
Thank you for purchasing your new D200 Dash Logger. Please check the contents of thepackage. You should have
received the following items:
• D200 Dash Logger
• Software CD
• Wiring Harness
• USB A to mini B cable
1.1 Overview
The D200 Dash Logger standard features include:
• 2MB Data Logging Memory
• Touchscreen Interface
• RS-232 Communication with Pass-Through
• Dual CAN 2.0B Interfaces
• 8 Analog Inputs
• 2 Speed Inputs
• 2 PWM Outputs
• On-board logging up to 100 times per second
1.1.1 On-Board Inputs and Outputs
The D200 Dash Logger has 8 analog inputs, 2 speed inputs, and 2 PWM outputs. The analog
inputs can be wired to any 0-5 VDC sensor. The calibration of voltage to function is
programmable on a 16-point table from the software. The analog input can be confi gured as one
of the following types of inputs.
• Voltage
• Percentage
• Data Log Enable
• Lambda
• Night Mode
• Position
• Pressure
• Temperature
• Disable Touchscreen
• Timing Beacon
When the input is defi ned in the software, the user has the ability to rename the input to a more specifi c name such as
renaming Analog 1, to Fuel Pressure. This detailed name will be used throughout the software and will be used in the
data log software. For monitoring the input on the screen, a four letter word or acronym can be used such as FPRS for
fuel pressure. In some cases a gauge can be chosen to match the resolution of an input. For example, if there are two
pressure inputs, one of which will reach a maximum of 95 PSI and the other will reach a maximum of 2350 PSI, then
the gauges 0-100 PSI and 0-2500 PSI can be assigned respectively.
