PCS D200 - AEM Data Properties

PCS D200 Dash Logger User Guide
Page 38
Ph: 804.227.3023
10511 Old Ridge Rd. Ashland, VA 23005
v 2.0
This section contains specifi c information for viewing and logging from devices listed below.
• AEM
• Autronic SMC,SM2
• Autronic SM4
• D200 On-Board Inputs
• Electromotive TEC2
• Electromotive TEC3
• Electromotive TEC GT
• FAST Classic Engine Controller
• FAST XFI Engine Controller
• Garmin 5Hz WAAS Enabled GPS
• Innovate Wideband
• Microtech
• Motec ECU
• PCS Transmission Controller
• PCS Xtended Fuel Controller (XFC)
• PCS Accelerometer Module
• PCS Exhaust Gas Temperature (EGT) Module
• Sakura FC-10
Table 1: AEM Data Properties
Parameter Data Log Title Label Big Gauge Small Gauge Tach Slider List Blocks Logged
Analog Input 08 ADCR08 AD08 No Yes No Yes Yes Yes
Analog Input 11 ADCR11 AD11 No Yes No Yes Yes Yes
Analog Input 13 ADCR13 AD13 No Yes No Yes Yes Yes
Analog Input 14 ADCR14 AD14 No Yes No Yes Yes Yes
Analog Input 15 ADCR17 AD17 No Yes No Yes Yes Yes
Analog Input 16 ADCR18 AD18 No Yes No Yes Yes Yes
Analog Input 17 ADCR15 AD15 No Yes No Yes Yes Yes
Analog Input 18 ADCR16 AD16 No Yes No Yes Yes Yes
Coolant Temperature Coolant Temp CLT No Yes No Yes Yes Yes
Engine RPM RPM RPM Yes No Yes Yes Yes Yes
Error Codes 1 Error 1 NA No No No No No Yes
Error Codes 2 Error 2 NA No No No No No Yes
Gear Gear GEAR No Yes No Yes Yes Yes
Load Input Load LOAD No Yes No Yes Yes Yes
Manifold Air Temperature Air Temp MAT No Yes No Yes Yes Yes
Oxygen Sensor 1 O2 1 O2 1 No Yes No Yes Yes Yes
Oxygen Sensor 2 O2 2 O2 2 No Yes No Yes Yes Yes
Throttle Position TPS TPS No Yes No Yes Yes Yes
Vehicle Speed VSS VSS Yes No No Yes Yes Yes
