PCS D200 Dash Logger User Guide

Page 44

Ph: 804.227.3023

10511 Old Ridge Rd. Ashland, VA 23005

v 2.0

Parameter Data Log Title Label Big Gauge Small Gauge Tach Slider List Blocks Logged

Elevation Elevation NA No No No No No Yes

Fix Dimension Fix Dimension NA No No No No No Yes

Latitude Latitude NA No No No No No Yes

Longitude Longitude NA No No No No No Yes

Magnetic Course Magnetic Course NA No No No No No Yes

Quality Quality NA No No No No No Yes

Satellite Mode Satellite Mode NA No No No No No Yes

Speed Over Ground Speed Over Ground NA No No No No No Yes

Status Status NA No No No No No Yes

Tracking Satellites Tracking Satellites NA No No No No No Yes

True Course True Course NA No No No No No Yes

UTC Date UTC Date NA No No No No No Yes

UTC Time UTC Time NA No No No No No

Parameter Data Log Title Label Big Gauge Small Gauge Tach Slider List Blocks Logged

Engine RPM RPM RPM Yes No Yes Yes Yes Yes

Throttle Position TPS TPS No Yes No Yes Yes Yes

Manifold Pressure MAP MAP No Yes No Yes Yes Yes

Coolant Temp CLT CLT No Yes No Yes Yes Yes

Manifold Air Temp MAT MAT No Yes No Yes Yes Yes

Air Fuel Ratio AFR AFR No Yes No Yes Yes Yes

Ignition Advance ADV ADV No Yes No Yes Yes Yes

Battery Voltage BATT BATT No Yes No Yes Yes Yes

Pulsewidth Pulsewidth PPW No Yes No Yes Yes Yes

Digital Input 1 DIN1 DIN1 No No No Yes Yes Yes

Parameter Data Log Title Label Big Gauge Small Gauge Tach Slider List Blocks Logged

Air Fuel Ratio Actual AFR AAFR No No No Yes Yes Yes

Table 10: Garmin GPS Data Properties

Table 12: Microtech Data Properties

Table 11: Innovate Wideband Data Properties
