Parameter Data Log Title Label Big Gauge Small Gauge Tach Slider List Blocks Logged
Engine RPM RPM RPM Yes No Yes Yes Yes Yes
Throttle Position TPS TPS No Yes No Yes Yes Yes
Manifold Pressure MAP MAP No No No Yes Yes Yes
Manifold Air Temp MAT MAT No Yes No Yes Yes Yes
Lambda 1 Lambda1 AFR1 No Yes No Yes Yes Yes
Lambda 2 Lambda2 AFR2 No Yes No Yes Yes Yes
Exhaust Pressure Exhaust Pressure EXPR No Yes No Yes Yes Yes
Mass Air Flow MAF MAF No No No Yes Yes Yes
Fuel Pressure Fuel Pressure FPRS No Yes No Yes Yes Yes
Oil Temp Oil Temp OTMP No Yes No Yes Yes Yes
Oil Pressure Oil Pressure OPRS No Yes No Yes Yes Yes
Exhaust Gas Temp 1 EGT 1 EGT1 No No No Yes Yes Yes
Exhaust Gas Temp 2 EGT 2 EGT2 No No No Yes Yes Yes
Battery Voltage Battery Voltage BATT No Yes No Yes Yes Yes
ECU Internal Temp ECU Temperature ETMP No Yes No Yes Yes Yes
Left Drive Speed Speed 1 SPD1 Yes No Yes Yes Yes Yes
Left Ground Speed Speed 2 SPD2 Yes No Yes Yes Yes Yes
Right Drive Speed Speed 3 SPD3 Yes No Yes Yes Yes Yes
Right Ground Speed Speed 4 SPD4 Yes No Yes Yes Yes Yes
Drive Speed Driven Speed DSPD Yes No Yes Yes Yes Yes
Ground Speed Ground Speed GSPD Yes No Yes Yes Yes Yes
Fuel Cut Level Fuel Cut Level FCUT No Yes No Yes Yes Yes
Ignition Advance Ignition Advance ADV No No No Yes Yes Yes
Load Point Load Point LDPT No No No Yes Yes Yes
Effi ciency Point Effi ciency Point EFPT No No No Yes Yes Yes
Fuel Used Fuel Used FUEL No No No Yes Yes Yes
Fuel Actual Pulse Width Fuel Actual PW PW No Yes No Yes Yes Yes
Fuel Effective Pulse Width Effective PW EFPW No Yes No Yes Yes Yes
Fuel Injectory Duty Cycle Injector Duty Cycle DUTY No No No Yes Yes Yes
Gear Gear GEAR No No No Yes Yes Yes
User Channel 1-4 User Channel 1-4 NA No No No No No Yes
Table 13: Motec ECU Data Properties
