PCS D200 - Electromotive TEC3 Data Properties

Page 41
Ph: 804.227.3023
10511 Old Ridge Rd. Ashland, VA 23005
v 2.0
Powertrain Control Solutions
Parameter Data Log Title Label Big Gauge Small Gauge Tach Slider List Blocks Logged
Actual Air Fuel Ratio AFR AAFR No Yes No Yes Yes Yes
Analog Input 1 Analog 1 AD1 No Yes No Yes Yes Yes
Analog Input 2 Analog 2 AD2 No Yes No Yes Yes Yes
Analog Input 3 Analog 3 AD3 No Yes No Yes Yes Yes
Analog Input 4 Analog 4 AD4 No Yes No Yes Yes Yes
Battery Voltage Bat. V. BATT No Yes No Yes Yes Yes
Coolant Temperature CLT CLT No Yes No Yes Yes Yes
Desired Air Fuel Ratio DAFR DAFR No Yes No Yes Yes Yes
EGO Correction EGOC EGOC No Yes No Yes Yes Yes
EGO Voltage EGO V EGOV No Yes No Yes Yes Yes
Engine RPM RPM RPM Yes No Yes Yes Yes Yes
General Purpose Output 1 GPO 1 GPO1 No Yes No Yes Yes Yes
General Purpose Output 2 GPO 2 GPO2 No Yes No Yes Yes Yes
General Purpose Output 3 NA GPO3 No No No Yes Yes No
General Purpose Output 4 NA GPO4 No No No Yes Yes No
Ignition Advance Advance ADV No Yes No Yes Yes Yes
Knock Knock KNK No Yes No Yes Yes Yes
Knock Retard KNK R KNKR No Yes No Yes Yes Yes
Manifold Air Temperature MAT MAT No Yes No Yes Yes Yes
Manifold Pressure MAP MAP No Yes No Yes Yes Yes
Primary Pulsewidth Primary PW PPW No Yes No Yes Yes Yes
Secondary Ignition Advance Sec ADV SADV No Yes No Yes Yes Yes
Staged Pulsewidth Staged PW SPW No Yes No Yes Yes Yes
Throttle Position TPS TPS No Yes No Yes Yes Yes
Total Fundamental Pulsewidth
TFPW TFPW No No No Yes Yes Yes
Table 6: Electromotive TEC3 Data Properties
