Parameter Data Log Title Label Big Gauge Small Gauge Tach Slider List Blocks Logged
Actual Air Fuel Ratio Actual AFR AAFR No Yes No Yes Yes Yes
Analog Input 1 Aux Analog 1 AD1 No Yes No Yes Yes Yes
Analog Input 2 Aux Analog 2 AD2 No Yes No Yes Yes Yes
Analog Input 3 Aux Analog 3 AD3 No Yes No Yes Yes Yes
Analog Input 4 Aux Analog 4 AD4 No Yes No Yes Yes Yes
Analog Input 5 Aux Analog 5 AD5 No Yes No Yes Yes Yes
Analog Input 6 Aux Analog 6 AD6 No Yes No Yes Yes Yes
Analog Input 7 Aux Analog 7 AD7 No Yes No Yes Yes Yes
Analog Input 8 Aux Analog 8 AD8 No Yes No Yes Yes Yes
Auxillary RPM AUX RPM ARPM Yes No Yes Yes Yes Yes
Battery Voltage Ignition Voltage BATT No Yes No Yes Yes Yes
Boost Duty Cycle Boost DC BSDC No Yes No Yes Yes Yes
Coolant Temperature CLT CLT No Yes No Yes Yes Yes
Desired Air Fuel Ratio Target AFR DAFR No Yes No Yes Yes Yes
Driveshaft RPM DS RPM DRPM Yes No Yes Yes Yes Yes
EGO Correction O2 Correction EGOC No Yes No Yes Yes Yes
EGR Duty Cycle EGR DC EGR No Yes No Yes Yes Yes
Engine RPM RPM RPM Yes No Yes Yes Yes Yes
Fuel Economy MPG ECON No No No Yes Yes Yes
Fuel Flow Lbs/Hr FLFW No No No Yes Yes Yes
Idle Air Control Motor IAC Position IAC No No No Yes Yes Yes
Ignition Advance Spark Advance ADV No Yes No Yes Yes Yes
Injector Duty Cycle Injector DC INJ No Yes No Yes Yes Yes
Knock Retard ESC Retard KNKR No Yes No Yes Yes Yes
Manifold Air Pressure MAP MAP No Yes No Yes Yes Yes
Manifold Air Temperature MAT MAT No Yes No Yes Yes Yes
Power Adder Ramp Retard PA Ramp Retard PARP No Yes No Yes Yes Yes
Power Adder Retard PA Retard PART No No No Yes Yes Yes
Power Adder Stage PA Stage PASG No No No Yes Yes Yes
Pulsewidth Base PW PW No Yes No Yes Yes Yes
Throttle Position TPS TPS No Yes No Yes Yes Yes
Vehicle Speed VSS VSS Yes No No Yes Yes Yes
Volumetric Effi ciency Vol. Effi ciency VE No No No Yes Yes Yes
Table 9: FAST XFI Data Properties
