PCS D200 - PCS Transmission Controller Data Properties

PCS D200 Dash Logger User Guide
Page 46
Ph: 804.227.3023
10511 Old Ridge Rd. Ashland, VA 23005
v 2.0
Parameter Data Log Title Label Big Gauge Small Gauge Tach Slider List Blocks Logged
4WD Low Enabled 4WD Low NA No No No No No Yes
Accumulator Pressure Accumulator Pressure APRS No Yes No Yes Yes Yes
Analog Input 1 Analog 1 AD1 No Yes No Yes Yes Yes
Analog Input 2 Analog 2 AD2 No Yes No Yes Yes Yes
Analog Input 3 Analog 3 AD3 No Yes No Yes Yes Yes
Analog Input 4 Analog 4 AD4 No Yes No Yes Yes Yes
Analog Input 5 Analog 5 AD5 No Yes No Yes Yes Yes
Analog Input 6 Analog 6 AD6 No Yes No Yes Yes Yes
Analog Input 7 Analog 7 AD7 No Yes No Yes Yes Yes
Analog Input 8 Analog 8 AD8 No Yes No Yes Yes Yes
Analog Input Failure Analog Failure NA No No No No No Yes
Calibration B Calibration B NA No No No No No Yes
Call TCC Lockup Cancel TCC Lockup NA No No No No No Yes
Cancel Overdrive NA NA No No No No No Yes
Coolant Temp CLT CLT No Yes No Yes Yes Ye
Current Gear Current Gear CGER No Yes No Yes Yes Yes
Desired Gear Desired Gear DGER No No No Yes Yes Yes
Digital Input 1 - 16 Digital Input 1 - 16 DIN1-16 No No No Yes Yes Yes
Digital Output 1 - 3 Digital Output 4 DO1-3 No No No Yes Yes Yes
Disable TCC Lockup Disable TCC Lockup NA No No No No No Yes
Dyno Mode Dyno Mode NA No No No No No Yes
Engine RPM RPM RPM Yes No Yes Yes Yes Yes
Fluid Temp 1 Fluid Temp 1 TMP1 No Yes No Yes Yes Yes
Fluid Temp 2 Fluid Temp 2 TMP2 No Yes No Yes Yes Yes
Lever Position Lever Position LPOS No Yes No Yes Yes Yes
Line Pressure Line Pressure LPRS No Yes No Yes Yes Yes
Manifold Pressure MAP MAP No Yes No Yes Yes Yes
PWM 1 PWM 1 PWM1 No Yes No Yes Yes Yes
PWM 2 PWM 2 PWM2 No Yes No Yes Yes Yes
PWM 3 PWM 3 PWM3 No Yes No Yes Yes Yes
PWM 4 PWM 4 PWM4 No Yes No Yes Yes Yes
PWM 5 PWM 5 PWM5 No Yes No Yes Yes Yes
PWM 6 PWM 6 PWM6 No Yes No Yes Yes Yes
Shaft RPM Driveshaft RPM SRPM Yes No Yes Yes Yes Yes
Simple Manual Mode Simple Manual Mode NA No No No No No Yes
Snow Mode Snow Mode NA No No No No No Yes
Speed Input 1 Speed 1 SPD1 Yes No Yes Yes Yes Yes
Speed Input 2 Speed 2 SPD2 Yes No Yes Yes Yes Yes
Speed Input 3 Speed 3 SPD3 Yes No Yes Yes Yes Yes
Speed Input 4 Speed 4 SPD4 Yes No Yes Yes Yes Yes
TCC Lockup Rate % TCC Duty TCC% No Yes No Yes Yes Yes
Throttle Position TPS TPS No Yes No Yes Yes Yes
Torque Converter Lockup TCC Lockup NA No No No No No Yes
Torque Converter Slip Torque Converter Slip % TSLP No Yes No Yes Yes Yes
Transmission Slip Transmission Slip % CSLP No Yes No Yes Yes Yes
True Manual Mode True Manual Mode NA No No No No No Yes
Turbine Speed Turbine Speed TRPM Yes No Yes Yes Yes Yes
Vehicle Slippage Vehicle Slip % VSLP No Yes No Yes Yes Yes
Vehicle Speed 1 VSS VSS Yes No No Yes Yes Yes
Vehicle Speed 2 VSS2 VSS2 Yes No No Yes Yes Yes
Wide Open Throttle Wide Open Throttle NA No No No No No Yes
Table 14: PCS Transmission Controller Data Properties
