PERI UP Flex Reinforcement Scaffold 75 and 100
67
Item no. Weight kg
124170
100572
6.770
7.590
Node Brace UBK
Node Brace UBK 75/200
Node Brace UBK 150/200
L X Y
2190 750 2000
2539 1500 2000
X
Y
L
Ø42,4
47
47
100416 9.520 Coupler Brace UBC 150/200
For special applications.
For connecting to Scaffold Tube Ø 48 mm.
1500
2
0
0
0
2
3
5
5
Ø48,3
