Peri UP Flex - Page 82

Ø38
Y
X
47
47
30
Ø22
40
404040
L
60
125125
X
VII
PERIUPFlexCoreComponents
Article no. Weight kg
131995
133900
131998
133903
132213
132004
132007
132010
132013
132016
132019
132025
132022
1.40
1.50
2.03
2.48
2.69
3.79
4.58
4.68
5.34
6.00
6.66
7.32
8.65
HorizontalLedgerUH-2
HorizontalLedgerUH-2 25
HorizontalLedgerUH-2 33
HorizontalLedgerUH-2 50
HorizontalLedgerUH-2 67
HorizontalLedgerUH-2 75
HorizontalLedgerUH-2 100
HorizontalLedgerUH-2 125
HorizontalLedgerUH-2 150
HorizontalLedgerUH-2 175
HorizontalLedgerUH-2 200
HorizontalLedgerUH-2 225
HorizontalLedgerUH-2 250
HorizontalLedgerUH-2 300
L X
204 250
284 330
454 500
624 670
704 750
954 1,000
1,204 1,250
1,454 1,500
1,704 1,750
1,954 2,000
2,204 2,250
2,454 2,500
2,954 3,000
Note
With length marking for easier identification.
PERIUPFlex – 2
nd
generation
Supplement to the Instructions for Assembly and Use
L X Y
2,190 750 2,000
2,285 1,000 2,000
1,625 1,250 1,000
2,401 1,250 2,000
1,821 1,500 1,000
2,152 1,500 1,500
2,539 1,500 2,000
2,246 2,000 1,000
2,521 2,000 1,500
2,860 2,000 2,000
2,696 2,500 1,000
2,930 2,500 1,500
3,226 2,500 2,000
3,131 3,000 1,000
3,356 3,000 1,500
3,625 3,000 2,000
NodeBraceUBK-2
NodeBraceUBK-2 75/200
NodeBraceUBK-2 100/200
NodeBraceUBK-2 125/100
NodeBraceUBK-2 125/200
NodeBraceUBK-2 150/100
NodeBraceUBK-2 150/150
NodeBraceUBK-2 150/200
NodeBraceUBK-2 200/100
NodeBraceUBK-2 200/150
NodeBraceUBK-2 200/200
NodeBraceUBK-2 250/100
NodeBraceUBK-2 250/150
NodeBraceUBK-2 250/200
NodeBraceUBK-2 300/100
NodeBraceUBK-2 300/150
NodeBraceUBK-2 300/200
4.96
5.11
3.88
5.30
4.22
4.82
5.53
4.97
5.47
6.08
5.77
6.19
6.72
6.60
6.96
7.42
133418
133421
133424
133427
133430
133433
133436
133439
133442
133445
133448
133451
133454
133457
133460
133463
