Peri UP Flex - Page 83

Ø42,4
2
0
L
X
Y
L
2
0
2
0
VIII
L X Y
901 1,000 500
1,250 1,000 1,000
1,677 1,000 1,500
2,136 1,000 2,000
1,347 1,500 500
1,601 1,500 1,000
1,953 1,500 1,500
2,358 1,500 2,000
2,500 1,750 2,000
1,820 2,000 500
2,016 2,000 1,000
2,305 2,000 1,500
2,658 2,000 2,000
2,062 2,250 500
2,236 2,250 1,000
2,829 2,250 2,000
2,462 2,500 1,000
2,705 2,500 1,500
3,010 2,500 2,000
2,795 3,000 500
2,926 3,000 1,000
3,133 3,000 1,500
3,400 3,000 2,000
LedgerBraces UBL-2
LedgerBraceUBL-2 100/ 50
LedgerBraceUBL-2 100/100
LedgerBraceUBL-2 100/150
LedgerBraceUBL-2 100/200
LedgerBraceUBL-2 150/ 50
LedgerBraceUBL-2 150/100
LedgerBraceUBL-2 150/150
LedgerBraceUBL-2 150/200
LedgerBraceUBL-2 175/200
LedgerBraceUBL-2 200/ 50
LedgerBraceUBL-2 200/100
LedgerBraceUBL-2 200/150
LedgerBraceUBL-2 200/200
LedgerBraceUBL-2 225/ 50
LedgerBraceUBL-2 225/100
LedgerBraceUBL-2 225/200
LedgerBraceUBL-2 250/100
LedgerBraceUBL-2 250/150
LedgerBraceUBL-2 250/200
LedgerBraceUBL-2 300/ 50
LedgerBraceUBL-2 300/100
LedgerBraceUBL-2 300/150
LedgerBraceUBL-2 300/200
2.12
2.81
3.66
4.58
3.01
3.51
4.21
5.02
5.31
3.95
4.34
4.92
5.62
4.43
4.78
5.96
5.23
5.71
6.32
5.90
6.16
6.57
7.10
132771
132773
132775
132777
132779
132781
132783
132785
132787
132789
132791
132793
132795
132797
132808
132810
132812
132814
132816
132827
132829
132831
132833
PERIUPFlexCoreComponents
Article no. Weight kg
PERIUPFlex – 2
nd
generation
Supplement to the Instructions for Assembly and Use
