7 Controls
7.01 Summary of control elements
O Main switch 1, see Chapter 7.02
O Pedal 2, see Chapter 7.03
O Control panel 3, see Chapter 7.04
O SD card reader and writer 4, see Chapter 7.05
Fig. 7 - 01
1
4
2
3
