PFAFF silberblau 8311 - Analog Outputs; Analog Inputs

Adjustment
90
13.05.04 Analog outputs
HW term SW term Function Comment
X24/1 X24/2
PWM 1
LED lighting (optional) / air
volume
X24/3 X24/4
PWM 2
LED lighting
X22 AIROUT Free 0..20mA
X23 RPRESSURE Free 0..20mA
13.05.05 Analog inputs
HW term SW term Function
X35 TEMP1 free, thermocouple evaluation
X36 TEMP2 free, thermocouple evaluation
X16 AE1 free, analog input 1 (0..10V)
X17 AE2 free, analog input 2 (0..10V)
X18 AE3 free, analog input 3 (0..20mA)
X19 AE4 free, analog input 4 (0..10V)
X14 Pedal Pedal evaluation
X45 Pedal2 optional 2nd pedal
X53
FORCE
Load cell 0..500N
