Adjustment
91
13.05.06 Communication
HW term SW term Function Comment
X28 RS232-USART2 Control panel interface RS232
X27 RS232-USART6 Reserve RS232
X21 RS422-USART3 Ultrasonic generator RS422
X15 CAN free CAN
X47 USB Programming / free USB
13.05.07 Data storage
HW term SW term Function Comment
X43 SD intern Micro SD card
X30 SD extern External SD card reader
X44 OTEdongle free
13.05.08 Other
HW term SW term Function Comment
X41 PWR Power supply 24V/5A
X24/3 X24/4 PWM2 LED lighting
X22 LUFTOUT free 0..20mA
X23 RDRUCK free 0..20mA
