PFAFF silberblau 8311 - Error Numbers

Adjustment
87
13.04.03 Error numbers
Error number Display text Description Response
11013
DC1: START WITH MOT OFF Start DC1 with the motor
current switched off
Troubleshoot
11014
DC1: SYNC CMD MASTER Sync. Command is not
permitted with DC1
Troubleshoot
11015
DC1: DRAG ERROR Following error DC1 Troubleshoot
11016
DC1: OVER CURRENT Overcurrent DC1 Troubleshoot
11017
DC1: ERR HOLDING TORQUE Torque detected when
the engine is not running
Troubleshoot
12013
DC2: START WITH MOT OFF Start DC2 with the motor
current switched off
Troubleshoot
12015
DC2: DRAG ERROR Following error DC2 Troubleshoot
12016
DC2: OVER CURRENT Overcurrent DC2 Troubleshoot
12017
DC2: ERR HOLDING TORQUE Torque detected when
the engine is not running
Troubleshoot
13013
DC3: START WITH MOT OFF Start DC3with the motor
current switched off
Troubleshoot
13015
DC3: DRAG ERROR Following error DC3 Troubleshoot
13016
DC3: OVER CURRENT Overcurrent DC3 Troubleshoot
13017
DC3: ERR HOLDING TORQUE Torque detected when
the engine is not running
Troubleshoot
14013
DC4: START WITH MOT OFF Start DC4with the motor
current switched off
Troubleshoot
14015
DC4: DRAG ERROR Following error DC4 Troubleshoot
14016
DC4: OVER CURRENT Overcurrent DC4 Troubleshoot
14017
DC4: ERR HOLDING TORQUE Torque detected when
the engine is not running
Troubleshoot
14018
DC4: ERR INIT TIMEOUT Lift motor home position
not reached
Troubleshoot
14019
DC4: ERR GAP OVERDRIVE Maximum force
exceeded (gap welding
Troubleshoot
14020
DC4: ERR OPERATOR
PROTECTION
Protective function
when closing the roller
Troubleshoot
14021
DC4: ERR NO ROLLER
INSTALLED
No welding wheel
installed
Troubleshoot
15001
RX ERROR RS422 INTERFACE Transmission error
reception USGEN
Troubleshoot
15004
ERROR: USGEN NOT REACTING Ultrasonic generator
does not respond
Troubleshoot
15005
MORE THAN 2 NAK Ultrasound generator
refuses to give orders
Troubleshoot
15006
ERROR: E1 E2 E3 E4
E1: 1st error byte
Bit position error text
0 error: amplitude
1 error: overcurrent
2 errors: bridge signal
3 Error: 24V supply
4 errors: temperature
5 Error: bridge voltage
6 Error: Release missing
7 Error: phase
E1, E2, E3, E4 error
numbers USGEN
Troubleshoot
