Adjustment
89
13.05 List of outputs and inputs
13
.05.01 Digital outputs
HW term SW term Function Comment
X1/1 Y1 Roller cooling Valve
X1/3 Y2 Puller up / down Valve
X1/5 free
X1/7 free
X11/1 (13/ 2 SSR US contact shutdown G12: X7/3
X11/3 USSTART Switch on analog US
X11/5 US PERFORMANCE Analogous to US power control
X11/7 G12SFG G12 start enable G12: X7/4
X12/1 OUT1 Programmable output 1
X12/3 OUT2 Programmable output 2
X12/5 RUNNING Welding start
X12/7 ERROR ERROR
13.05.02 Digital input
HW term SW term Function
X2/2 E1 Monitoring switch roll off
X2/3 E2 free
X3/2 IN1 programmable input 1
X3/3 IN2 programmable input 2
X4/2
E5
free
X4/3 E6 free
X5/2 E7 free
X5/3 Puller Coding input puller
X6/2 Titan194 Coding input titanium sonotrode 104mm
X6/3 Steel113 Coding input steel sonotrode 113mm
X7/2 DUAL DUAL Cut & Seal coding input
X7/3 Amboss35 Coding input anvil wheel 35mm
X8/2 E13 Initiator lifting motor
X8/3 E14 free
X9/2 E15 free
X9/3 E16 free
X10/2
E17
free
X10/3 RES Factory Reset
13.05 .03 Motors
HW term SW term Function Comment
X34 M1 Drive roller below DC motor
X33 M2 Drive roller above DC motor
X32 M3 Drive puller (optional) DC motor
X25/X49 M4 Lifting motor DC motor
X51/X52 M5 DUAL knife position Stepping motor
