Access: Menu [Measurement] [Calibrated leak settings]
Choice - Setting limit
1)
Unit To be selected
Unit of calibrated leak used for calibration
2)
mbar · l/s
Pa · m
3
/s
Torr · l/s
mTorr · l/s
atm · cc/s
sccm
sccs
ppm
3)
Leak value To be set
Value of calibrated leak used for calibration
2)
1 · 10
-18
– 1 · 10
+18
Loss per year (%) To be set
Set the loss per year for the calibrated leak used for calibration
2)
0 – 99
Reference temperature
(°C)
To be set
Reference temperature for the calibrated leak used for calibration
2)
0 – 99
Temperature coefficient
(%/°C)
To be set
Temperature coefficient for the calibrated leak temperature used for
calibration
2)
0.0 – 9.9
Date To be set
Month and year of calibration for the calibrated leak used for calibra-
tion
2)
Format: MM/YYYY
-
Type To be selected
Source of displayed temperature
● Internal: measured temperature by the internal calibrated leak
temperature sensor
● External: set temperature by the operator
Internal
Externeal
Internal Temperature
(°C)
(if internal ‘Type’)
Read only
Temperature of the detector’s internal calibrated leak
-
External Temperature
(°C)
(if external ‘Type’)
To be set
Configuration of external temperature
0 – 99
1) Initial setting: see chapter “Tree diagram to the Settings menu”
2) Use the information indicated on the calibrated leak used for calibration or on its calibration certificate.
3) If sniffer test method selected
When the parameters are saved, all the data from all the set calibrated leaks (1 internal leak (
4
He) and
3 external leaks (
4
He, Mass 3 and H
2
)) is stored.
8.1.5 Target value
The target value is the value of the calibrated leak measured and corrected for temperature, taking into
account the loss/year.
The temperature and the loss/year must be taken into account on calculating the target value.
This information is provided on the calibrated leak identification label.
Access: Menu [Measure] [Target Value]
Target value Read only
Settings menu
52/98
