Access: [Advanced] [Input/Output] [Serial Link 1] menu
Choice - Setting limit
1)
Handshake To be selected Yes
No
Power Pin 9 Read only
The power depends on the mode selected.
5 V
24 V
1) Initial setting: see chapter “Tree diagram to the Settings menu”
2) 'Table' mode only
Access: [Advanced] [Input/Output] [Serial Link 2] menu
Choice - Setting limit
1)
Type Serial link 2 is not used. Not used
1) Initial setting: see chapter “Tree diagram to the Settings menu”
I/O Connector
Access: Menu [Advanced] [Input/Output] [I/O connector]
The detector is equipped with a 15-pin D-Sub I/O communication interface (see chapter “15-pin input/
output communication interface”).
8.6.2 Service
Access to the Service menu is password protected.
Reserved for the Service Centers.
Settings menu
