Pfeiffer Vacuum ASM 310 - Access - Password

Access: Menu [Configuration] [Screen settings] Choice - Set-
ting limit
1)
Leak rate bar-
graph
See details below -
Application win-
dows
Std-by Value To be selected
Leak rate display in ‘Stand-by’ mode
Hide
Show
Show inlet pressure To be selected
Inlet pressure display.
Hide
Show
Show second pressure To be selected
Display of the cell pressure or of an external gauge.
● None: no display
● Cell.: analyzer cell pressure display
● Ext.: external gauge pressure display (at the cus-
tomer’s expense)
The external gauge (at the customer's expense) is a
gauge installed on the customer's application, connect-
ed to the 37-pin I/O board.
None
Cell.
Ext.
Show synoptic To be selected
Synoptic display (see chapter “Navigation”).
Hide
Show
Reset screen
parameters
Function launching
This function is used to load the default settings of the control panel.
-
1) Initial setting: see chapter “Tree diagram to the Settings menu”
For quick access from the main screen, configure a function key to [PAGING] (see chapter
“Function keys”).
Leak rate bargraph details
This menu is used to enter the bargraph settings.
Access: Menu [Configuration] [Leak rate bargraph]
Choice - Setting limit
1)
Zoom on set point To be enabled
Zoom on set point is used to display on the bargraph the reject set point
centered on 2 decades.
Enabled
Disabled
High decade To be set
High decade (max) of the bargraph
-12– +6
Low decade To be set
Low decade (min) of the bargraph
-13 – +5
Lower display limit To be set
This limit defines the lower display limit for the measured leak rate.
The measured leak rate is not displayed if it is lower than the set lower dis-
play limit.
1 · 10
-13
– 1 · 10
+06
Show 2
nd
digit
To be enabled
Display of a second digit after the decimal point for digital display of the
leak rate
Enabled
Disabled
1) Initial setting: see chapter “Tree diagram to the Settings menu”
8.3.5 Access - Password
This menu is used to manage the access rights to the various menus and/or screens.
Regardless of the user level, a password is required to access this menu.
The default password is 5555.
The password is not saved in the control panel. If the password is forgotten, it can be found
using the RS-232: see RS-232 operating instructions.
Settings menu
63/98
