Flat panel touch
screen monitor
Power supply
Pre-vacuum pump
11 USB cable
Connects the monitor to the Phenom (rear) USB port.
12 Monitor controls
y - switches the monitor on and off.
LED - lights up green when the monitor is switched on.
Displays monitor menu and selects menu items.
– and +
Navigate through and adjust monitor settings.
13 Touch screen
Operates the Phenom together with the rotary knob and the mouse (ProX / Pro).
14 0 / I switch
15 Connection for power cable
16 Fuse holder
Contains the fuses.
17 Connection for pre-vacuum pumphose
