58
System
Imaging Modes
Resolution
Illumination
Digital Image Detection
Image Format
Image Resolution Options
Data Storage
Sample Stage
Sample Size
Sample Loading Time
Dimensions & Weight
Room Temperature
Humidity
Power
Recommended Table Size
Maximum operation altitude
9. Technical specifications
Imaging module, 19" touch screen monitor (ProX / Pro), 17" touch screen monitor
(Pure), Rotary knob, mouse (ProX / Pro), diaphragm vacuum pump, power supply,
USB flash drive.
L
ight Optical Magnification fixed: 20 - 120 x (ProX / Pro)
20 x, fixed (Pure)
Electron Optical: Magnification range: 80 – 100,000x, digital zoom: 12 x (ProX / Pro)
70 – 20,000x, digital zoom: 12 x (Pure)
17 nm (ProX /Pro)
30 nm (Pure)
Light Optical : Selectable axial and off-axis LEDs
Electron Optical: Long lifetime thermionic source (CeB6)
Light Optical Color CCD Camera
Electron Optical: High Sensitivity Backscatter Electron Detector (multi-mode)
JPEG, TIFF, BMP
456 x 456, 684 x 684, 1024 x 1024 and 2048 x 2048 pixels
USB 2.0 Flash drive
Computer controlled, motorized X and Y
Maximum sample dimensions up to 32 mm (Ø) or 100 mm(h)
Light Optical: < 5s
Electron Optical: < 30s
Imaging module: 286 mm / 11" (w) x 566 mm / 22" (d) x 495 mm / 19" (h),
50kg / 110 lbs
Diaphragm vacuum pump: 145 mm / 5.5" (w) x 220 / 8.5" (d) x 213 mm / 8" (h)
4.5kg / 9.9 lbs
Power supply: 156 mm / 6" (w) x 300 mm / 12" (h) x 74 mm / 3" (d), 3kg / 6.6 lbs
Monitor: 429 mm / 17" (w) x 379 mm / 15" (h) x 207 mm / 8" (d),
7.9 kg / 17.4 lbs (ProX / Pro)
355 mm / 14" (w) x 340 mm / 13" (h) x 203 mm / 8" (d),
3.2kg / 7 lbs (Pure)
15 °C ~ 30 °C (59 °F ~ 86 °F)
< 80% RH
Single phase AC 110 - 230Volt, 50/60Hz, 300W (max.)
120 cm / 47" x 75 cm / 9.5", load rating of 100 kg / 220 lbs
2000 m
