29
Note
!
3 Enter server name, share path, domain name, user name and password. Enter the
user name and password that you use to get access to Windows on your computer.
For example: ‘//server001/folder/username’. Use forward slashes instead of
backslashes.
– If a USB Flash drive is inserted in the Phenom, the network settings are saved on it.
When you later re-insert this USB Flash drive, the network settings will be filled in
a
utomatically and you will only have to enter your password.
– If the USB Flash drive is removed from the Phenom, the network share is also
disconnected as a security measure.
4 Touch OK to confirm.
> If that fails (because you haven't filled in all fields, or something is wrong), a
message with the details of the problem will be displayed.
> Images will now be stored on the selected network share.
5 Touch Image in the screen selection bar to return to the Image screen.
Storing images
T
ouch (A) to store the image displayed in the main viewing window (fig. 3,1).
Touch (B) to store the image displayed in the optical overview window (fig. 3,11).
Touch (C) to store the image displayed in the electron overview window (fig. 3,3).
Parameters for settings associated with storing images can be selected on the
Settings screen.
> Images will be stored on the selected storage location (USB flash drive or network
share). The storage location will be displayed in the status window.
When storing images on the supplied USB Flash drive (fig. 1,10), make sure the USB Flash
drive is correctly formatted and inserted into one of the Phenom USB ports (fig. 1,7 / fig. 2,6).
The USB Flash drive can be inserted at any time. For formatting the USB Flash drive refer to
5.6.1 ‘USB stick’.
A
C
B
