Philips DVDR75/001 - Page 15

Directions For Use
EN 15DVDR70 & DVDR75/0x1 3.
20
Connecting audio devices to the digital audio socket
At the back of the DVD recorder there is a digital audio output socket DIGITAL AUDIO OUT for an coaxial cable. These can be used to connect the following: •) an A/V receiver or an A/V amplifier with a digital multichannel sound decoder •) a receiver with twochannel digital stereo (PCM)
Digital multichannel sound Digital multi-channel sound offers the best possible sound quality. You will need a multi-channel A/V receiver or amplifier that supports at least one of the audio formats of the DVD recorder (MPEG2, Dolby Digital and DTS). Consult the operating instructions for your receiver to find out which audio formats it supports.
?
a All I can hear from my loudspeakers is a loud distorted noise
b The receiver is not compatible with the digital audio format of the DVD
recorder. The audio format of the DVD disc is displayed in the status window when you switch to anoter language. Playback in six-channel digital surround sound is only possible if the receiver has a digital multi-channel sound decoder.
Problem
Connecting additional devices
19
Connect camcorder to the front sockets
To copy camcorder recordings, you can use the front sockets. These sockets are located behind the flap on the left hand side. Best picture quality If you have a DV or Digital 8 camcorder, connect the DV IN input of the DVD recorder to the appropriate DV output on the camcorder. When films are transferred the original recording date and time are stored as DVD subtitles. On playback, this data can be displayed on the TV screen by using the '
E
' function (Subtitle).
Very good picture quality If you have a Hi8 or S-VHS(C) camcorder, connect the S-VIDEO input of the DVD recorder to the appropriate S-VHS output on the camcorder. You must also connect the audio input left AUDIO right on the DVD recorder to the audio output on the camcorder. Good picture quality If you have a camcorder that only has a single video output (Composite Video, CVBS), connect the VIDEO input on the DVD recorder to the appropriate output on the camcorder. You must also connect the audio input left AUDIO right on the DVD recorder to the audio output on the camcorder.
Connecting audio devices to the analogue audio sockets
Two audio output sockets OUT L AUDIO R are located on the back of the DVD recorder (audio signal output left/right) These can be used to connect the following: •) a receiver with Dolby Surround Pro Logic •) a receiver with twochannel analogue stereo
Can I use the 'Phono' input on my amplifier? This socket (input) on the amplifier is designed only for record players without preamplifiers. Do not use this input for connecting the DVD recorder. The DVD recorder or the amplifier may be damaged as a result.
?
