Philips DVDR75/001 - Page 204

Circuit-, IC descriptions and list of abbreviations
EN 204 DVDR70 & DVDR75/0x19.
PINNING
OVERVIEW
Name Pins Type Function
System
RESETn 1 In
SYSCLK (27MHz) 1 In
Host Interface
HO_A(21:1) 21 In
HO_D(15:0) 16 In/Out
HO_BEn(1:0) 2 In
HO_RWn 1 In
HO_CSLn 1 In
HO_CSHn 1 In
HO_A22 1 In
HO_WAIT 1 Out
HO_PROCCLK 1 In
Memory Interface
M_A(13:0) 14 Out
M_DQ(15:0) 16 In/Out
M_RASn 1 Out
M_CASn 1 Out
M_WEn 1 Out
M_LDQM 1 Out
M_UDQM 1 Out
M_CLKOUT 1 Out
M_CLKEN 1 Out
Basic Engine Interface
BE_BCLK 1 In
BE_DATI 1 In
BE_WCLK 1 In
BE_SYNC 1 In/Out
BE_FLAG 1 In
BE_V4 1 In
BE_DATO 1 Out
Video Encoder Interface
VE_D(15:0) 16 In
VE_DSn 1 Out
VE_DTACKn 1 In
VE_VIP_ERROR 1 In Signal coming from SAA7114
Audio Encoder Interface
AE_CSn 1 Out
AE_BCLK 1 In/Out
(CR151,CR157)
AE_WCLK 1 In/Out
(CR151,CR157)
AE_DATA 1 In
(CR157)
