Circuit-, IC descriptions and list of abbreviations
EN 205DVDR70 & DVDR75/0x1 9.
Decoder Interface
D_PAR_D(7:0) 8 Out
D_PAR_DVALID 1 Out
D_PAR_STR 1 Out
D_PAR_REQ 1 In
D_PAR_SYNC 1 Out
D_WCLK 1 Out
D_V4 1 Out
Audio Clock Control
ACC_FID 1 In
(CR200)
ACC_PWM 1 Out
ACC_ACLK_OSC 1 In
ACC_ACLK_DAI 1 In
ACC_ACLK_PLL 1 In
ACC_ACLK_DEC 1 Out
VBI Extractor
VBI_IPD(7:0) 8 In
VBI_ICLK 1 In
UART 1
UART1_RX 1 In
UART1_TX 1 Out (OC)
UART1_CTSn 1 In
UART1_RTSn 1 Out (OC)
UART 2
UART2_RX 1 In
UART2_TX 1 Out (OC)
UART2_CTSn 1 In
UART2_RTSn 1 Out (OC)
UART 3 (VSM1B)
UART3_RX 1 In
UART3_TX 1 Out
UART3_CTSn 1 In
UART3_RTSn 1 Out
Interrupt Controller
EXTINT(3:0) 4 In From: VEnc, AEnc, BE, VSync (STi5505)
CPUINT(1:0) 2 Out (OC)
JTAG
TCK 1 In Boundary Scan
TDI 1 In
TDO 1 Out/Z
TMS 1 In
TRSTn 1 In
Test
TEST0 1 In Amsal Test
TEST1 1 In
Power Supply
VDD 20 Power 10% of total pins package
VSS 20 Power 10% of total pins package
Total Pins 208
