Philips IntelliVue X2 User Manual

Measurement Specifications 24 Specifications
269
Interfering Gas and Vapor Effects On CO
2
Measurement Values
The specified deviations for M3002A/M3014A are valid when the appropriate corrections are switched
on and set correctly.
CO
2
Alarm
Specifications Range Adjustment Delay
etCO
2
High 20 to 95 mmHg (2 to 13 kPa) 1 mmHg (0.1 kPa) M8102A/M3014A/M3016A: less than
14 seconds
M3015A: less than18 seconds.
etCO
2
Low 10 to 90 mHg (1 to 12 kPa)
imCO
2
High 2 to 20 mmHg
(0.3 to 3.0 kPa)
steps of 1 mmHg
(0.1 kPa)
M8102A/M3014A/M3016A: less than
14 seconds
M3015A: less than18 seconds.
awRR High Adult/pedi: 10 to 100 rpm
Neo: 30 to 150 rpm
under 20 rpm: 1 rpm
steps
over 20 rpm:5 rpm
steps
M8102A/M3014A/M3016A: less than
14 seconds
M3015A: less than18 seconds.
awRR Low Adult/pedi: 0 to 95 rpm
Neo: 0 to 145 rpm
M3015A:
settings <20 rpm: less than 8 seconds
>20 rpm: less than 18 seconds
M8102A/M3014A/M3016A
settings <20 rpm: less than 4 seconds
>20 rpm: less than 14 seconds
Apnea delay 10 to 40 seconds 5second steps set apnea delay time +4seconds
(M8102A/M3014A/M3016A) or
8seconds (M3015A)
Gas or Vapor
Gas Level
(% volume fraction)
M3002A/M3014A M3015A
Additional deviation due to gas interference, measured
at 0 - 40 mmHg CO
2
Nitrous Oxide 60 ±1 mmHg ±5 %
Halothane 4 ±2 mmHg ±5 %
Enflurane 5 ±2 mmHg ±5 %
Isoflurane 5 ±2 mmHg ±5 %
Sevoflurane 5 ±2 mmHg ±5 %
Xenon 80 -5 mmHg ±5 %
Helium 50 ±1 mmHg ±5 %
Metered dose inhaler
propellants
-not specified for use
Desflurane 15 +5 mmHg ±5 %
Ethanol 0.1 ±1 mmHg ±5 %
Isopropanol 0.1 ±1 mmHg ±5 %
Acetone 0.1 ±1 mmHg ±5 %
Methane 1.0 ±1 mmHg ±5 %
