Controls, Indicators and Connectors
X2 Overview
1 On/Standby Switch
2 Power and battery indicators (see “X2
Controls and Indicators” on page 12)
3 3.5-inch TFT LCD touchscreen QVGA
display
4 Alarm lamps (see “X2 Controls and
Indicators” on page 12)
5 Battery eject button
6 Keys (see “X2 Controls and Indicators” on
page 12)
7 Measurement connectors (see “X2 Patient
Connectors, Right Side” on page 13)
8 Battery
1
2
4
3
5
6
1
2
3
4
6
8
5
7
