Ordering data and technical data
107708_en_08 PHOENIX CONTACT 95 / 112
Number of supported devices Max. 63 (per station)
Number of local bus devices that can be connected Max. 63 (observe current consumption)
NOTE: Electronics may be damaged if overloaded
Note the logical current consumption of each device when configuring an Axioline F station. This is specified
in every module-specific data sheet. The current consumption can differ depending on the individual module.
The permissible number of devices that can be connected therefore depends on the specific station structure.
System limits
PROFINET
Device function PROFINET controller, PROFINET device
Number of supported devices
AXC F 1152 Max. 16 (on PROFINET controller)
AXC F 2152 Max. 64 (on PROFINET controller)
Specification Version 2.3
Conformance class A
Update rate
AXC F 1152 Min. 1 ms (4 devices)
Min. 4 ms (16 devices)
AXC F 2152 Min. 1 ms (4 devices)
Min. 16 ms (64 devices)
Number of slots 1
Vendor ID 00B0
hex
Device ID
AXC F 1152 0169
hex
AXC F 2152 0142
hex
Communications voltage U
L
feed-in (the supply of the Axioline F local bus U
Bus
is generated from U
L
)
Supply voltage 24 V DC
Supply voltage range 19.2 V DC ... 30 V DC (including all tolerances, ripple included)
Current consumption Typ. 200 mA (with no I/Os and U
L
= 24 V)
Max. 442 mA (with 1 A at U
Bus
for the I/Os and U
L
= 24 V)
Power consumption Typ. 4.8 W (with no I/Os)
Max. 10.6 W (with 1 A load at U
Bus
for the I/Os)
Surge protection for supply voltage Electronic
Polarity reversal protection for supply voltage Electronic
NOTE: Electronics may be damaged if overloaded
Provide external protection for the 24 V U
L
range. If you use a fuse, the power supply unit must be capable of
supplying four times the nominal current of the fuse. This ensures that the fuse trips reliably in the event of a
fault.
Axioline F local bus supply (U
Bus
)
Supply voltage 5 V DC (via bus base module)
Power supply 1A
