PIAGGIO MP3 400 i.e. - Installing the Fixed Driving Half-Pulley

- Insert the half-pulley on the crankshaft.
- Insert the spacer bushing.
Installing the fixed driving half-pulley
- Insert the spacer.
- Install the fixed driving half-pulley and check that
it is in contact with the spacer and with the guide
bushing of the moving driving pulley.
- Remove the flat washer and the spring washer
as shown in the figure.
Engine MP3 400 i.e.
ENG - 16
