Hub oil
Check
-Park the vehicle on its centre stand on flat ground;
- Remove the oil dipstick «A», dry it with a clean
cloth and put it back into its hole tightening it
completely;
Remove the dipstick and check that the oil level is
slightly over the second notch starting from the
lower end; if the level is below the MAX mark, it
needs to be filled up with the right amount of hub
oil.
-Screw up the oil dipstick again and make sure it
is locked properly into place.
Replacement
-Remove the oil cap «A».
- Unscrew the oil drainage cap "B" and drain out
all the oil.
- Screw in the drainage cap again and fill the hub
with the prescribed oil.
Recommended products
AGIP ROTRA 80W-90 Rear hub oil
SAE 80W/90 Oil that exceeds the requirements of
API GL3 specifications
Characteristic
Rear hub oil
Capacity approximately 250 cc
MP3 400 i.e. Maintenance
MAIN - 7
