PIAGGIO MP3 400 i.e. - Centre-Stand; Shock Absorber Lower Clamp

Locking torques (N*m)
Shock absorber lower clamp 33 ÷ 41 Upper shock absorber clamp 33 ÷ 41
Centre-stand
- Use a jack to support the vehicle properly.
- Remove the two stand return springs.
- Working from both sides, undo the two bolts con-
necting it to the supporting plate.
- To refit, follow the removal steps but in reverse order; be careful to tighten to the prescribed torque.
Locking torques (N*m)
Centre stand bolt 31 ÷ 39
Suspensions MP3 400 i.e.
SUSP - 54
