PIAGGIO MP3 400 i.e. - Front Handlebar Cover; Instrument Panel

Instrument panel
- Remove the front handlebar cover.
- Remove the front shield.
- Remove the shield back plate upper side.
- Unscrew the six fixing screws and remove the
instrument panel.
Front handlebar cover
- Remove the upper cap by operating on the Allen
screw indicated in the figure.
- Remove the two brake pump caps.
- Remove the two screws under the brake pump
caps previously removed.
MP3 400 i.e. Chassis
CHAS - 3
