- Unscrew the two pairs of screws in the lower part
of the half-handlebar.
- Release the handlebar control locks.
- Remove the front handlebar cover.
Headlight assy.
Remove the radiator cover.
Remove the two wheelhouses with the turn indi-
cator.
Unscrew the two screws fixing the wheelhouse to
the shield.
Disconnect the cable guide; after that, turn the
wheelhouse anticlockwise (inwards) to release it
from the shield supports.
To remove the shield central finishing, remove the
PIAGGIO clip-on badge paying attention not to
spoil the paint, unscrew the screw underneath and
remove the finish carefully.
Chassis MP3 400 i.e.
CHAS - 4
