Remove the four screws «A» and disconnect the
wiring.
See also
Radiator cover
Frame central cover
Remove the three screws on the right and the left
side.
Open the refuelling compartment and remove the
tank cap so as to remove the central cover.
Disconnect the cable, refuelling compartment
opening.
See also
Seat
Handles and top side fairings
Knee-guard
MP3 400 i.e. Chassis
CHAS - 5
