PIAGGIO MP3 400 i.e. - Rear brake disc

- Check that the pistons and their seats show no
scratches.
- Wash and blow all the components carefully
- Fit the O-rings and new dust guards
- Refit the pistons in their seats being careful to
lubricate with brake fluid
- Re-couple the half callipers and lock the two
screws at the specified torque
Locking torques (N*m)
Calliper coupling screw 22 ÷ 27
Refitting
- To fit the front brake callipers, follow the removal steps but in reverse order; be careful to tighten the
screws to the prescribed torque.
Locking torques (N*m)
Screw tightening calliper to the support 20 ÷ 25
Rear brake disc
MP3 400 i.e. Braking system
BRAK SYS - 5
