PIAGGIO MP3 400 i.e. - Anti-Vibration Roller Screw 16.7 -; Inspecting the Clutch Drum; Removing the Driven Pulley

Anti-vibration roller screw 16.7 - 19.6
Removing the driven pulley
- Remove the clutch bell.
- Remove the fixed driving half-pulley.
- Remove the driven pulley assembly with the belt.
Inspecting the clutch drum
- Check that the clutch bell is not worn or damaged.
- Measure the clutch bell inside diameter.
N.B.
CHECK THE ECCENTRICITY MEASURED, 0.2
MM MAX.
Characteristic
Max. value:
160.5 mm
Standard value:
160.2 mm
Engine MP3 400 i.e.
ENG - 6
