Fuses
The electrical system has twelve fuses divided into
two fuse boxes to protect the different installation
circuits. One of them is inside the battery compart-
ment «A» and the other is at the internal side of
the right footrest «B».To have access, loosen the
screw «C» and remove the plastic cover. The chart
shows the position and characteristics of the fuses
in the vehicle.
CAUTION
BEFORE REPLACING THE BLOWN FUSE,
FIND AND SOLVE THE FAILURE THAT
CAUSED IT TO BLOW. NEVER TRY TO RE-
PLACE THE FUSE WITH ANY OTHER MATERI-
AL (E.G., A PIECE OF ELECTRIC WIRE).
MP3 400 i.e. Electrical system
ELE SYS - 25
