Specification Desc./Quantity
6 Fuse 20 A
7 Fuse 7.5 A
8 Key switch contacts
9 Engine stop switch
10 Fuse 7.5 A
11 Fuse 15A
12 Fuse 10 A
13 Starter button
14 Injection load remote control
15 Start-up remote control relay
16 Electric fan starter
17 Starter motor
18 Electric fan
19 Fuel pump
20 HV coil
21 Fuel injector
22 Lambda sensor
23 Rpm indicator
24 "WARNING" light
25 Immobilizer LED
26 Diagnostics socket connector
27 Starter remote control
Troubleshooting procedure
Engine does not start
ENGINE DOES NOT START IF ONLY PULLED
Possible Cause Operation
Immobiliser enabling signal System not encoded
System not efficient, repair according to the indi-
cations of the self-diagnosis
Presence of faults detected by the self diagnosis Pump relay
HV coil
Injector
revolution timing sensor
Fuel supply Fuel in the tank
Fuel pump activation
Fuel pressure (low)
Injector capacity (low)
Power to the spark plug Shielded spark-plug cap HV coil (secondary insu-
lation)
Parameter reliability Coolant temperature
Distribution timing - injection ignition
Intake air temperature
End of compression pressure End of compression pressure
Injection MP3 400 i.e.
INJEC - 8
