- Refit the water pump cover and tighten the 6 fix-
ing screws to the prescribed torque.
Locking torques (N*m)
Pump cover fixing screws: 3 ÷ 4
Refitting the flywheel cover
- Install a new oil filter, lubricate the gasket, screw
on and finally tighten to the prescribed torque.
Locking torques (N*m)
Engine oil filter 12 - 16
- Install the supply hose to the cylinder and con-
nect the return hose to the pump cover using 3 new
clamps.
N.B.
TIGHTEN THE CLAMPS USING APPROPRIATE
PLIERS, PAYING ATTENTION NOT TO CON-
STRICT THE HOSES BUT ALSO TAKING CARE
TO TIGHTEN THE CLAMPS SUFFICIENTLY.
- Install the pre-filter again and insert the engine oil
drain plug, tightening to the prescribed torque.
- Refill the engine with the prescribed type of oil.
Recommended products
AGIP CITY HI TEC 4T Engine oil
SAE 5W-40, API SL, ACEA A3, JASO MA Syn-
thetic oil
Locking torques (N*m)
Engine oil drainage plug 24 ÷ 30
Engine MP3 400 i.e.
ENG - 34
