This section è is devoted to the operations that can be carried out on the vehicle's bodywork.
Seat
- Raise the saddle.
- Undo the screw shown in the figure, remove the
cover and disconnect the rider presence sensor
connector.
- Remove the three fixing screws shown in the fig-
ure.
Rear handlebar cover
After removing the front part of the handlebar cov-
er, access the two screws fixing the rear part to the
handlebar, as indicated in the photograph.
Chassis MP3 400 i.e.
CHAS - 2
