PIAGGIO MP3 400 i.e. - Rear brake pads

- Remove the pads.
Characteristic
Minimum value
1.5 mm
Refitting
- Follow the removal steps but in reverse order; check that the Benzing snap ring of the pads is in good
conditions.
Rear brake pads
Removal
Proceed as follows:
- Remove the rear brake calliper
- Remove the two pins holding the brake pads.
- Remove the pads, paying attention to the pad re-
taining spring.
- Check the thickness of the pads.
If the thickness is less than the minimum value,
replace the pads with new pads.
Characteristic
Minimum value
1.5 mm
Refitting
- To fit the rear brake pads, follow the removal steps but in reverse order; be careful to tighten the screws
to the prescribed torque.
Locking torques (N*m)
Screws tightening the pad fixing pin 20 ÷ 25 Nm
Fill
Braking system MP3 400 i.e.
BRAK SYS - 10
